Rosco Custom LitePad CCT 95 is a tunable white, flat panel LED light source providing even, indirect lighting and which, at only 8mm thick, is perfectly suited to virtually any backlighting installation or to projects where only a cool, low profile light source can be used. LitePad’s patented system is comprised of indirect LED sources machined into a cast acrylic panel. Light amplifying channels etched into the rear surface of the plastic sheet smoothly and evenly distribute light across the entire surface of the LitePad. This durable and reliable construction can be fabricated in virtually any size or shape and is easily installed. A variety of options are available to customize light output, power management, and dimming control. Rosco project consultants are available to assist in specifying the optimal configuration of panels and accessories for your project.
The tunable white Custom LitePad CCT 95 offers all the same features of Rosco’s standard LitePad product but includes a variable color temperature light output. Two separate channels of LEDs allow you to dial in the precise quality of white light, from 2700K to 6500K. Dimming and control accessories sold separately.
LED Placement: Fully Customizable
LED Spacing: 9mm
IP65 available on request
Panel Thickness: 8mm
Maximum Size: 59" (1.5m) x 118" (3.0m)
Panel Weight: 2 lb/ft2 (9.5 kg/m2)
Operating Temp Range: -22°F (-30°C) to +104°F (+ 40°C)
Color/Color Temp: 2700K to 6500K - Full Range
Photometric Data: See Files in Documents tab
Input Power: 12V or 24V DC
Lead / Connector: 20 AWG wire with 2.1mm x 5.5mm barrel connector
Three Standard Lead Wire Exit Options: Corner, Notched Corner, Rear of Panel
Customizable options available on request.
